Description
Railroad Short Name: FXE
Features:
- Era: 2022 to Present
- Series 4660 to 4699; built August – October 2007
- Fully-assembled
- Multiple road numbers
- LED-illuminated front, rear and rectangle side walkway lights*
- LED-illuminated front deck-mounted ditch lights
- Printed and LED lighted number boards*
- Semi-scale coupler buffers equipped with die-cast metal semi-scale Type E knuckle couplers
- Inside loop uncoupling levers with down brackets
- Single trainline hose with silver gladhand
- Dual front dummy Multiple Unit (MU) receptacles mounted to front anticlimber supports
- Front raised and rear flush pilot-mounted Multiple Unit (MU) receptacles
- See-through round-hole stepwell steps
- Walkway with front anticlimber and support brackets
- GE “nub” pattern walkway tread
- Early handrails with wrap over stanchion heads left long rail for capacitor box clearance and right long rail with bolted head on 2nd lower stanchion
- Narrow profile end handrails
- Sand box clean out door with knuckle buster latch
- Front nose headlight
- Left nose door with window
- Front high-mounted (cab) numberboard housings
- Single cab side blue flag holder
- Left side under cab front access bolted X panel; rear door with square corrugated grille
- Early cab with optional 4 side windows; without barrel bolt latches on subbase doors
- Detailed cab interior with separate floor, rear wall, seats, and control stand
- In cab grade crossing camera mounted on right side
- Tinted cab side windows
- Photoetched metal rock guard screens over all cab windows
- Wi-Tronix Violet Exterior Cab Cameras mounted on both cab sides
- Tall mirror mounted in front of sliding cab side windows on both sides
- Switching mirror mounted under rear sliding window on engineer side
- Cab roof GE communications handler octagonal dome, medium rectangle antenna dome with conduit
- Inverter Cabinet with Bolted and hinged access door, top two X panels same size, three lower X panels with 4 – 6 – 4 Bolt Pattern
- See-through dynamic brake exhaust
- Left side dynamic brake cab: tri blower dynamic brake with flush exhaust
- Etched metal see-through dynamic brake intake grilles with blower motors visible inside
- Right side dynamic brake cab: door with grille, small grille, door with grille, and door with grille
- Dynamic brake cab door with low door handle and low mounted door handle bumper
- Short right side air intake grille
- Left side auxiliary cab: 3 short doors with latches on the #2 door and narrow auxiliary cab filter box door with X panel in front
- Capacitor box on left side walkway
- Right side auxiliary cab: 4 doors with latches on #1 and #4 doors
- ES44 style engine cab doors: latched first door in each set of three
- Two engine cab roof lift rings
- Lost wax brass cast Nathan AirChime K5HL horn mounted on engine cab roof
- ES44 style exhaust stack
- Left side exhaust cab doors: latched last door in set of three
- Flush heat exchanger housing with two-piece wide slot grille
- Late raised radiator grille
- 22 individually applied etched metal see-through radiator intake and exhaust grilles on sides and top of radiator compartment
- Left side radiator cab grille arrangement: Raised doors. Grilles – tall-short-tall-short-tall, no grille under brake wheel short front angled grille and two-piece rear angled grille
- Right side radiator cab grille arrangement: Raised doors. Grilles – tall, short, tall, tall, tall, tall, short, tall, short front angled grill, two-piece rear angled grille
- Angled water fill box
- High mounted vertical rear headlight
- Rear wide-spaced dual dummy Multiple Unit (MU) receptacles
- Accurately profiled frame with separately applied plumbing and cabling
- Early GE Steerable trucks with separately applied brake cylinders, air plumbing, and rotating bearing caps
- Rust-color painted wheelsets
- Square handbrake chain bracket
- Toilet drain with interior handle
- AEI tag mounted on bracket below the right sidesill
- Dual Graham-White (Salem) accordion 824 air filters
- 5,300-gallon fuel tank with internal waste retention tank, digital fuel gauge, vertical fuel gauge, and round fuel gauge
- Dual fuel fills per side with rear fill “blanked”
- Angled top left side fuel tank top box
- Digital Fuel Gauges
- Short crankcase drainpipe
- Factory-applied wire grab irons, snowplow with grab irons, spare knuckles, trainline hoses with silver gladhands, 3-hose MU clusters with silver gladhands, uncoupling levers, windshield wipers, mirrors, sunshades, air tanks, fuel tank mounted electronic bell, brake wheel, and more
- Motor with 5-pole skew wound armature
- Dual flywheels
- All-wheel drive
- All-wheel electrical pick-up
- Directional LED headlights
- Printing and lettering legible under magnification
- Operates on Code 70, 83, and 100 rail
- Packaging safely stores model
- Minimum Radius: 18”
- Recommended Radius: 22”
DCC & Sound Features:
- ESU-LokSound 5 DCC and Sound decoder with “Full Throttle”
- Two (2) cube-type speakers
- Accurate GEVO-12 prime mover and auxiliary sounds, horn, bell, and more
- ESU-designed PowerPack with two (2) super capacitors***
- Operates on both DC and DCC layouts
